Chiller Unit

Quickly find the chiller that meets your requirements!

Cooling capacity

Set temperature (℃)

Cooling method



*If you are unsure of the required cooling capacity,
Please search from "Search for a chiller that meets your requirements"​

For more information on the calculation method, please refer to "How to determine cooling capacity."

Object

Volume of object [m³]

Temperature before cooling [℃]

Temperature after cooling [℃]

Cooling time [sec]

safety factor

Required cooling capacity 0.0 kW

Enter the required values

For more information on the calculation method, please refer to "How to determine cooling capacity."

Object

circulating water flow rate [ℓ/min]

Load outlet temperature [℃]

Load inlet temperature [℃]

safety factor

Required cooling capacity 0.0 kW

Enter the required values


Regarding price and delivery time
inquiry Regarding products and specification
inquiry
Various materials
Download here

Purchase Support

View
the lineup Inquire
about pricing Consultation regarding
implementation Request a free
test unit

I'm looking for a chiller...
how
Should I choose??

Help with selection here

How to choose a chiller that's easy for everyone to understand​
 Consult us about your selection

Our chillers
To current customers

Support for products you are using
Click here

Instruction manual Repair/ inspections request Recommended replacement model

Quick Selection

HFC alternative chiller

PCU-NE1500

PCU Series

CE ETL
PCU-NE1500

Uses non-freon-gas refrigerant, eliminating the need for fluorocarbon management

HFC alternative

Cooling capacity(W)*1
1300／1400
Thermal capacity(W)
230／350
Temperature control stability (℃)
±0.1
circulating water rating flow rate (ℓ/min)
15／15

(50/60Hz)

Learn more
Download
catalog handling
Instructions CAD
data drawing
PDF Price enquiry inquiry

HFC alternative chiller

PCU-NE2500

PCU Series

CE ETL
PCU-NE2500

Uses non-freon-gas refrigerant, eliminating the need for fluorocarbon management

HFC alternative

Cooling capacity(W)*1
2300／2600
Thermal capacity(W)
400／600
Temperature control stability (℃)
±0.1
circulating water rating flow rate (ℓ/min)
15／15

(50/60Hz)

Learn more
Download
catalog handling
Instructions CAD
data drawing
PDF Price enquiry inquiry

HFC alternative chiller

PCU-NE6000

PCU Series

CE ETL
PCU-NE6000

Uses non-freon-gas refrigerant, eliminating the need for fluorocarbon management

HFC alternative

Cooling capacity(W)*1
5400／6000
Thermal capacity(W)
1200／1600
Temperature control stability (℃)
±0.1
circulating water rating flow rate (ℓ/min)
30／35

(50/60Hz)

Learn more
Download
catalog handling
Instructions CAD
data drawing
PDF Price enquiry inquiry

HFC alternative chiller

PCU-NE2500W

PCU Series

CE ETL
PCU-NE2500W

Uses non-freon-gas refrigerant, eliminating the need for fluorocarbon management

HFC alternative

Cooling capacity(W)*1
2600／3100
Thermal capacity(W)
280／450
Temperature control stability (℃)
±0.1
circulating water rating flow rate (ℓ/min)
15／15

(50/60Hz)

Learn more
Download
catalog handling
Instructions CAD
data drawing
PDF Price enquiry inquiry

HFC alternative chiller

PCU-NE6000W

PCU Series

CE ETL
PCU-NE6000W

Uses non-freon-gas refrigerant, eliminating the need for fluorocarbon management

HFC alternative

Cooling capacity(W)*1
5400／6000
Thermal capacity(W)
1400／1900
Temperature control stability (℃)
±0.1
circulating water rating flow rate (ℓ/min)
30／35

(50/60Hz)

Learn more
Download
catalog handling
Instructions CAD
data drawing
PDF Price enquiry inquiry

High-performance chiller

PCU-SL10000

PCU Series

CE
PCU-SL10000

Air-cooling type, equipped with IOF sensing
High-stability, high-speed response chiller

Energy saving

Outdoors possible

Cooling capacity(W)*1
10300／10300
Thermal capacity(W)
2500
Circulating water temperature range
5～45
Temperature control stability (℃)
±0.1
circulating water flow rate range (ℓ/min)
20～70

(50/60Hz)

Learn more
Download
catalog handling
Instructions CAD
data drawing
PDF Price enquiry inquiry

High-performance chiller

PCU-SL14000

PCU Series

CE
PCU-SL14000

Air-cooling type, equipped with IOF sensing
High-stability, high-speed response chiller

Energy saving

Outdoors possible

Cooling capacity(W)*1
13300／13300
Thermal capacity(W)
2500
Circulating water temperature range
5～45
Temperature control stability (℃)
±0.1
circulating water flow rate range (ℓ/min)
20～70

(50/60Hz)

Learn more
Download
catalog handling
Instructions CAD
data drawing
PDF Price enquiry inquiry

High-performance chiller

PCU-SL12000W

PCU Series

CE
PCU-SL12000W

Water-cooled, equipped with IOF sensing
High-stability, high-speed response chiller

Energy saving

Outdoors possible

Cooling capacity(W)*1
12000／12000
Thermal capacity(W)
2500
Circulating water temperature range
5～45
Temperature control stability (℃)
±0.1
circulating water flow rate range (ℓ/min)
20～70

(50/60Hz)

Learn more
Download
catalog handling
Instructions CAD
data drawing
PDF Price enquiry inquiry

High-performance chiller

PCU-SL15000W

PCU Series

CE
PCU-SL15000W

Water-cooled, equipped with IOF sensing
High-stability, high-speed response chiller

Energy saving

Outdoors possible

Cooling capacity(W)*1
14200／14200
Thermal capacity(W)
2500
Circulating water temperature range
5～45
Temperature control stability (℃)
±0.1
circulating water flow rate range (ℓ/min)
20～70

(50/60Hz)

Learn more
Download
catalog handling
Instructions CAD
data drawing
PDF Price enquiry inquiry

Precision chillers

PCU-1610R

PCU Series

CE
PCU-1610R

Compact type with a width of 400 mm
Space saving

wide range

High stability

Cooling capacity(W)*1
1200／1300
Circulating water temperature range
-10～80
Temperature control stability (℃)
±0.05 (high stability mode)
rating flow rate (ℓ/min)
10／12

(50/60Hz)

Learn more
Download
catalog handling
Instructions CAD
data drawing
PDF Price enquiry inquiry

Precision chillers

PCU-3310R

PCU Series

CE
PCU-3310R

cooling capacity 3000W class
Demonstrates its capabilities in a variety of applications

Cooling capacity(W)*1
2800／3100
Circulating water temperature range
-10～80
Temperature control stability (℃)
±0.05 (high stability mode)
rating flow rate (ℓ/min)
18／20

(50/60Hz)

Learn more
Download
catalog handling
Instructions CAD
data drawing
PDF Price enquiry inquiry

Precision chillers

PCU-6320R

PCU Series

CE
PCU-6320R

Air-cooling type, cooling capacity 6000W class
Demonstrates its capacity even under high loads

Cooling capacity(W)*1
5800／6200
Circulating water temperature range
-10～80
Temperature control stability (℃)
±0.10 (high stability mode)
rating flow rate (ℓ/min)
35／40

(50/60Hz)

Learn more
Download
catalog handling
Instructions CAD
data drawing
PDF Price enquiry inquiry

Precision chillers

PCU-6330R

PCU Series

CE
PCU-6330R

Air-cooling type, cooling capacity 6000W class
Demonstrates its capacity even under high loads

Cooling capacity(W)*1
5700／6100
Circulating water temperature range
-10～80
Temperature control stability (℃)
±0.10 (high stability mode)
rating flow rate (ℓ/min)
35／40

(50/60Hz)

Learn more
Download
catalog handling
Instructions CAD
data drawing
PDF Price enquiry inquiry

Precision chillers

PCU-W3610R

PCU Series

CE
PCU-W3610R

cooling capacity 3500W class
Demonstrates its capabilities in a variety of applications

Cooling capacity(W)*1
3100／3400
Circulating water temperature range
-10～80
Temperature control stability (℃)
±0.05 (high stability mode)
rating flow rate (ℓ/min)
18／20

(50/60Hz)

Learn more
Download
catalog handling
Instructions CAD
data drawing
PDF Price enquiry inquiry

Precision chillers

PCU-W6630R

PCU Series

CE
PCU-W6630R

Water-cooled medium-sized type
Suitable for a variety of uses

Cooling capacity(W)*1
5900／6400
Circulating water temperature range
-10～80
Temperature control stability (℃)
±0.10 (high stability mode)
rating flow rate (ℓ/min)
35／40

(50/60Hz)

Learn more
Download
catalog handling
Instructions CAD
data drawing
PDF Price enquiry inquiry

Precision chillers

PCU-W9130R

PCU Series

CE
PCU-W9130R

Water-cooled type, cooling capacity 9000W class
Stability even under high load

Cooling capacity(W)*1
7900／8900
Circulating water temperature range
-10～80
Temperature control stability (℃)
±0.10 (high stability mode)
rating flow rate (ℓ/min)
35／40

(50/60Hz)

Learn more
Download
catalog handling
Instructions CAD
data drawing
PDF Price enquiry inquiry

HFC alternative pump/tankless chiller

PCU-F3000

PCU Series

PCU-F3000

Pump and tankless structure
Meets the diverse cooling needs of manufacturing site

HFC alternative

Cooling capacity(W)*1
2800／3200
Temperature control stability (℃)
±0.1
circulating water flow rate range (ℓ/min)
10～60
circulating water rating flow rate (ℓ/min)
15／15

(50/60Hz)

Learn more
Download
catalog handling
Instructions CAD
data drawing
PDF Price enquiry inquiry

HFC alternative pump/tankless chiller

PCU-F7000

PCU Series

PCU-F7000

Pump and tankless structure
Meets the diverse cooling needs of manufacturing site

HFC alternative

Cooling capacity(W)*1
5700／6700
Temperature control stability (℃)
±0.1
circulating water flow rate range (ℓ/min)
10～60
circulating water rating flow rate (ℓ/min)
30／30

(50/60Hz)

Learn more
Download
catalog handling
Instructions CAD
data drawing
PDF Price enquiry inquiry
