Small type chiller
This space-saving, compact chiller can be installed even in limited spaces within a factory, achieving stable temperature control. It is useful in a wide range of locations and applications, including manufacturing site and research facilities.
Suitable for the following customers
- I want to minimize the installation space as much as possible
| Model | Cooling capacity (W) |
Heating capacity (W) |
Circulating water temperature range (°C) |
Temperature control precision (°C) |
External dimensions (HxWxD) (mm) |
||
|---|---|---|---|---|---|---|---|
| Air-cooling type PCU-NE1500 |
1300／1400 | 230／350 | ±0.1 | 610×400×445 |
Product Catalog - Instruction manual |
||
| Air-cooling type PCU-NE2500 |
2300／2600 | 400／600 | ±0.1 | 697×400×600 |
Product Catalog - Instruction manual |
||
| Air-cooling type PCU-NE6000 |
5400／6000 | 1200／1600 | ±0.1 | 997×400×600 |
Product Catalog - Instruction manual |
||
| Water-cooling type PCU-NE2500W |
2600／3100 | 280／450 | ±0.1 | 697×400×600 |
Product Catalog - Instruction manual |
||
| Water-cooling type PCU-NE6000W |
5400／6000 | 1400／1900 | ±0.1 | 997×400×600 |
Product Catalog - Instruction manual |
||
| Air-cooling type PCU-1610R |
1200／1300 | 700 | -10～80 | ±0.05 (high-precision mode) | 950×400×770 |
Product Catalog - Instruction manual |
|
| Air-cooling type PCU-3310R |
2800／3100 | 1000 | -10～80 | ±0.05 (high-precision mode) | 1000×440×800 |
Product Catalog - Instruction manual |
|
| Air-cooling type PCU-6320R |
5800／6200 | 6000 | -10～80 | ±0.10 (high-precision mode) | 1250×440×800 |
Product Catalog - Instruction manual |
|
| Air-cooling type PCU-6330R |
5700／6100 | 6000 | -10～80 | ±0.10 (high-precision mode) | 1250×440×800 |
Product Catalog - Instruction manual |
|
| Water-cooling type PCU-W3610R |
3100／3400 | 1000 | -10～80 | ±0.05 (high-precision mode) | 1000×440×800 |
Product Catalog - Instruction manual |
|
| Water-cooling type PCU-W6630R |
5900／6400 | 6000 | -10～80 | ±0.10 (high-precision mode) | 1250×440×800 |
Product Catalog - Instruction manual |
|
| Water-cooling type PCU-W9130R |
7900／8900 | 6000 | -10～80 | ±0.10 (high-precision mode) | 1250×440×800 |
Product Catalog - Instruction manual |
Select a chiller based on its features
Product Category
The PCU-NE series is a new chiller that is the first in the industry to use HFC-alternative refrigerants and also comes equipped with two industry-first features: a drive recorder and a time calendar.
This chiller combines high energy-saving performance of up to 50% with durability that can withstand harsh field environment and outdoor use. It also has high-temperature precision and is suitable for a variety of applications.
Controls circulating water over wide range of -10°C to 80°C and with a high precision of ±0.05°C. Widely used in manufacturing, development, and research fields.
HFC alternative pump/tankless chiller
The PCU-F series has a structure that does not have a pump or tank inside the main body. This structure greatly improves design freedom and allows for flexible response to a variety of needs.
