Precision air conditioners (TCU/ECU) Product lineup

Non-freon-gas & Energy saving models

Non-freon-gas & Energy saving modelsPAU Series

Apiste PAU-GR series uses R1234yf, HFC Alternatives, which is an environmentally friendly refrigerant, so you will be freed from management issues such as the emitted amount or the cost to waste.
Moreover Apiste original refrigerant circuit technology (pricise refrigerant flow control, new inverter control, advanced algorithm, heaterless control) has achieved great enegy saving performance and high accuracy temperature & humidity control and stability of ±0.1℃/±0.5%RH.

To the features/model list(10)

Model   Cooling capacity
(W)
Thermal capacity
(W)
Air outlet volume
(m3/min)

PAU-GR300SE Air-cooling type Temperature control 315 (430) 250 1.2(Normal mode) Product details
PAU-GR800SE Air-cooling type Temperature control 880 (1000) 640 3.0(Normal mode) Product details
PAU-GR1800SE Air-cooling type Temperature control 1680 (2000) 1080 5.0(Normal mode) Product details
PAU-GR3000SE Air-cooling type Temperature control 3000 (3500) 1180 10.0(Normal mode) Product details
PAU-GR8000SE Air-cooling type Temperature control 8000 (9200) 4700 30.0(Normal mode) Product details
PAU-GR800SE-HC Air-cooling type Temperature and humidity control 850 (970) 630 3.0(Normal mode) Product details
PAU-GR1800SE-HC Air-cooling type Temperature and humidity control 1675 (2000) 1235 5.0(Normal mode) Product details
PAU-GR3000SE-HC Air-cooling type Temperature and humidity control 3000 (3500) 3400 (1150) 10.0(Normal mode) Product details
PAU-GR8000SE-HC Air-cooling type Temperature and humidity control 8000 (9600) 11000 (4100) 30.0(Normal mode) Product details
PAU-GRW9000SE-HC Water-cooling type Temperature and humidity control 9000 (10700) 9100 (3700) 30.0(Normal mode) Product details
Energy saving & High precision / normal models

Energy saving & High precision / normal modelsPAU Series

Apiste PAU series offer high quality temperature & humidity control required for limited space at various manufacturing sites, inspection and testing processes.
Apiste technology in PAU-AZ series (pricise refrigerant flow control, original algorithm, heaterless control) has achieved great enegy saving performance and high accuracy temperature & humidity control and stability of ±0.1℃/±0.5%RH.

To the features/model list(10)

Energy saving & High precision model list

Energy saving & High precision models

Model   Cooling capacity
(W)
Thermal capacity
(W)
Air flow
(m3/min)

PAU-AZ1800SE Air-cooling type Temperature control 1300/1500 1900/2100 4.8/5.0 Product details
PAU-AZ3000SE Air-cooling type Temperature control 2600/2950 3250/3550 9.5/10 Product details
PAU-AZ7000SE Air-cooling type Temperature control 6400/7200 9100/9900 20/22 Product details
PAU-AZW8000SE Water-cooling type Temperature control 7700/8000 10400/10700 21/24 Product details
PAU-AZW8000SE-HC Water-cooling type Temperature and humidity control 7000/8000 9700/10700 20/23 Product details
PAU-AZ2000SE-DR Air-cooling type Dehumidification 4200/4800 7200/7800 5.0/6.0 Product details

Nomal models

Model   Cooling capacity
(W)
Thermal capacity
(W)
Air flow
(m3/min)

PAU-300S Air-cooling type Temperature control 230/280 600 0.8/1.0 Product details
PAU-AR800S Air-cooling type Temperature control 430/510 1000 1.8/2.0 Product details
PAU-A920S-HC Air-cooling type Temperature and humidity control 550/650 1000 2.1/2.3 Product details
PAU-A1400S-HC Air-cooling type Temperature and humidity control 1200/1400 2000 3.7/4.8 Product details
Clean fan filter unit

Clean fan filter unitPAU Series

FFU(fan filter units) achieve a clean environment according to the needs of the installation environment. It takes in air containing particles with the high static pressure fan and supplies clean air with a high level of cleanliness by passing it through a HEPA filter. 7 standard models with different processing air flows are offered in the lineup, allowing you to choose a unit according to the volume of the target space and the level of the cleanliness required. A pressure loss in the wind speed can be detected at any time as it is equipped with a standard heated wire wind speed sensor to prevent the ventilation frequency from dropping due to clogging of the filter. Air cleaning and temperature and humidity control can also be carried out by combining it with a precision air conditioner.

To the features/model list(10)

Model   Processed air volume
(m3/min)*
Dust collection efficiency
PAU-01FFU About 0.8/0.9 or more 99.97% or more for 0.3 μm particles Product details
PAU-03FFU About 2.8/3.0 or more 99.97% or more for 0.3 μm particles Product details
PAU-05FFU About 4.8/5.0 or more 99.97% or more for 0.3 µm particles Product details
PAU-05FFU-DM About 4.8/5.0 or more 99.97% or more for 0.3 μm particles Product details
PAU-A11FFU 11 or more 99.97% or more for 0.3 μm particles Product details
PAU-A14FFU 14 or more 99.97% or more for 0.3 μm particles Product details
PAU-A17FFU 17 or more 99.97% or more for 0.3 μm particles Product details
PAU-A11FFU-ULPA 9 or more 99.999% or more for 0.1 μm particles Product details
PAU-A14FFU-ULPA 12 or more 99.999% or more for 0.1 μm particles Product details
PAU-A17FFU-ULPA 14 or more 99.999% or more for 0.1 μm particles Product details

* Average value with no load.
