Chillers
HFC alternative, energy-saving, wide range,
More than just cooling
Apiste Chiller
Chiller PCU series
What is a Chiller?
A chiller is a device that cools or regulates the temperature of a heat source by circulating water controlled at a constant temperature. It is used for a variety of purposes, including industrial machinery, medical machinery, scientific and laboratory equipment, and food processing machinery. It is also called a chiller, chiller unit, unit cooler, or cooling water circulator, but these are all synonymous. It is also used as ancillary equipment for cooling semiconductor and FPD manufacturing equipment.
Apiste 's PCU series chillers support manufacturing site with a lineup tailored to various applications. For more information on chiller applications and detailed explanations, please refer to the article below.
Product Category
The PCU-NE series is a new chiller that is the first in the industry to use non-freon-gas refrigerant also comes equipped with two industry-first features: a drive recorder and a time calendar.
This chiller combines high energy-saving performance of up to 50% with durability that can withstand harsh field environment and outdoor use. It also has high temperature stability and is suitable for a variety of applications.
Controls circulating water over wide range of -10℃ to 80℃ and with a high stability of ±0.05℃. Widely used in manufacturing, development, and research fields.
HFC alternative pump/tankless chiller
The PCU-F series has a structure that does not have a pump or tank inside the main body. This structure greatly improves design freedom and allows for flexible response to a variety of needs.
Select a chiller based on its features
Chiller option
How to select a chiller
Four steps to confirm and decide on a chiller
It is important to select a chiller that is suited to the equipment and work being cooled, and it is also important to match the conditions and circumstances of use with the chiller's functions, performance, and specification.
-
STEP1
Determination of circulating water temperature
The circulating water temperature is determined based on the optimum temperature of the workpiece and equipment. Learn more -
STEP2
Determining the cooling method and location
Decide on the cooling method and installation location, such as Air-cooling type or water-cooled, indoors or outdoors. Learn more -
STEP3
Calculation of required cooling capacity
Calculate the required cooling capacity. Learn more -
STEP4
Determining Pump Capacity
Determine the pump capacity (head) required to circulate the cooling water. Learn more
Easy Chiller Selection Tool
If you have already decided on the conditions for the chiller you want to select, you can easily select the chiller that suits your purpose from this page.
Choose from chiller cooling capacity
Chiller installation examples
Chiller FAQs
What is the service life of the chiller?
The service life (lifespan) of a chiller varies depending on the equipment's usage and installation environment.
To maintain the cooling performance of the chiller and ensure stable use,
Please carry out daily inspections and periodic inspections and maintenance.
Please check the following items as part of your daily inspections.
- Installation method: Do not place Weight objects on the device or apply excessive force to piping, etc.
- Installation environment: Ambient temperature and humidity must be within specification range.
- Leakage: There should be no cooling water or circulating water leaks from the piping connections.
- circulating water: The amount of circulating water should not be too small.
- Operating condition: No abnormal noise, vibration, strange odor or smoke.
- Cooling water: Temperature, flow rate, and pressure must be within specification range. There must be no dirt or foreign matter mixed in.
- Filter: Not clogging.
Additionally, the following symptoms may be due to a breakdown or performance over time.
- The water temperature does not reach the set temperature (does not cool)
- Compressor won't start or stops
- Lots of vibration and noise
- No power supply
In the above cases, symptoms may improve with appropriate treatment,
If the symptoms do not improve, please contact our sales department or visit our website.
Please refer to the instruction manual for details on daily inspections and how to deal with equipment problems.
Please contact us here for inquiries regarding repairs, inspections, etc.
Please let me know the price and delivery date of the chiller.
We carry out strict inventory management for each product every day so that we can deliver the products you need to our customers without making them wait.
In the unlikely event that a problem occurs and you need a product immediately, we can respond with a short delivery time.
For prices and delivery times, please contact us here.
How do I select a chiller?
To select a chiller, it is necessary to understand the heat output of the equipment. There are several ways to calculate this, including calculating it from the equipment specification, calculating it from the flow rate and temperature difference of circulating water, or estimating it from the existing cooling equipment.
For details, please refer to "How to Select a Chiller (PCU Series)."
